1060 Mill Finish Aluminum

1060 Mill Finish Aluminum Sheet and Coil for Forming, Electrical and Industrial Applications



1060 aluminum sheet and coil belong to the commercially pure 1xxx series and contain at least 99.6% aluminum. The grade is valued for its high formability, good corrosion resistance, electrical and thermal conductivity, weldability and clean mill-finish surface. It is a non-heat-treatable aluminum grade, so its strength is controlled mainly by cold working and the selected temper.



For most buyers, 1060 is selected when purity, forming performance and conductivity matter more than high mechanical strength. It is widely used for stamped and formed components, electrical parts, reflectors, signs, heat-transfer products, insulation components and general sheet-metal fabrication. For highly loaded or structural parts, a stronger alloy such as 3003, 5052 or 6061 may be more appropriate.



What Is 1060 Mill Finish Aluminum?



Mill finish means that the aluminum retains the natural surface produced by rolling, without a paint coating, decorative film or anodized layer. The surface normally has a clean metallic appearance and may show light rolling lines or minor tone differences that are typical of industrial mill-finished aluminum.



Because the surface is uncoated, 1060 mill finish aluminum can be used directly for many industrial components or processed further by anodizing, polishing, brushing, embossing, printing, laminating or color coating. For visible decorative parts, the required surface quality and protective-film specification should be agreed before production.



Available 1060 Aluminum Product Forms and Processing



Worthwill supplies 1060 aluminum in sheet, coil and slit-coil form. Full-width coil can be slit to narrower widths, while sheet material can be leveled and cut to the required length. Production should be selected according to thickness, width, temper, flatness, edge condition, surface requirement and downstream processing.



Product Form	Typical Supply	Common Uses
1060 Aluminum Coil	Full-width coil or slit coil	Roll forming, stamping, insulation, electrical parts and continuous production
1060 Aluminum Sheet	Standard sheet or cut-to-length sheet	Panels, signs, reflectors, covers, electrical components and fabricated parts
1060 Aluminum Strip	Precision-slit narrow coil	Electrical components, stamping, winding, trim and small formed parts



Processing options: slitting, leveling, cut-to-length, edge trimming, protective film, paper interleaving and application-specific export packing can be discussed according to the order.



How to Choose the Right 1060 Aluminum Temper



Temper has a direct effect on strength, hardness, elongation and forming performance. A softer temper is normally preferred for demanding drawing or spinning, while harder tempers are selected when better stiffness and shape retention are required.



Temper	General Characteristics	Typical Selection
O	Soft annealed condition with the highest formability	Deep drawing, spinning and components requiring extensive forming
H12 / H14	Moderate strength with useful bendability and forming performance	General sheet-metal fabrication, signs, reflectors, panels and stamping
H16 / H18	Higher hardness and better shape retention with lower ductility	Flat components, narrow strip and applications with limited forming
H22 / H24 / H26	Strain-hardened and partially annealed conditions	Applications requiring controlled strength with practical formability



For a new stamped, bent or deep-drawn component, send the drawing, thickness, bend radius and forming method when possible. The correct temper should be selected from the actual manufacturing process rather than from hardness or price alone.



Key Properties of 1060 Aluminum



Minimum 99.6% aluminum: 1060 is a commercially pure aluminum grade with a higher minimum aluminum content than 1050 and 1100. It is commonly specified when material purity, conductivity and forming performance are more important than high structural strength.



Excellent formability: 1060 aluminum can be bent, stamped, drawn, spun and roll formed. O temper provides the highest forming capability, while H12 and H14 provide additional stiffness for general fabrication.



High electrical and thermal conductivity: The high-purity composition makes 1060 suitable for electrical conductors, busbars, heat-spreading components and other applications where efficient transfer of electricity or heat is important and the mechanical load is moderate.



Good corrosion resistance: Aluminum naturally forms a protective oxide layer that provides good resistance in many atmospheric, indoor and general industrial environments. Suitability for aggressive chemical, marine or other severe environments should be confirmed against the actual service conditions.



Good weldability and finishing: 1060 can be welded using appropriate aluminum welding procedures and can also be anodized, polished, coated, printed or laminated after suitable surface preparation.



Easy fabrication but relatively low strength: 1060 is practical for forming and high-volume sheet-metal processing, but it should not be selected as a substitute for higher-strength aluminum alloys when structural performance is the main design requirement.



Typical Applications of 1060 Aluminum Sheet and Coil



Electrical and conductive components: busbars, conductor plates, electrical connectors, transformer-related components and other fabricated electrical parts where aluminum purity and conductivity are important.



Lighting and reflectors: lamp reflectors, lighting covers, reflective components and base material that will be polished, anodized or otherwise surface-finished.



Heat-transfer and thermal-management parts: heat-spreading plates, heat-exchanger components, cooling-related sheet-metal parts and other applications benefiting from high thermal conductivity.



Signs and nameplates: traffic signs, industrial signs, nameplates, printed panels and decorative components that require light weight, corrosion resistance and easy fabrication.



Chemical and industrial equipment: equipment covers, panels, liners, containers and fabricated components used in service conditions compatible with commercially pure aluminum.



General stamping and forming: housings, covers, gaskets, shallow- or deep-drawn parts, insulation components, HVAC products and custom OEM sheet-metal parts.



Mill Finish Surface: What Buyers Should Expect



A mill finish is a natural industrial rolled surface rather than a mirror-polished, brushed, anodized or prepainted decorative surface. Light rolling lines, small tone differences or minor handling traces can occur and do not normally affect forming or industrial performance.



If the aluminum will remain visible after fabrication, specify the required appearance standard, whether one or both sides are appearance surfaces, protective-film requirements and any unacceptable defects before production. A confirmed reference sample is useful when appearance consistency is critical.



For painting, printing, bonding or laminating, cleaning and pretreatment should be selected according to the final coating or adhesive system. An untreated mill-finish surface should not automatically be considered ready for decorative coating without suitable pretreatment.



1060 vs 1050, 1100 and 3003 Aluminum



Alloy	General Position	Choose It When
1060	Minimum 99.6% aluminum with excellent forming and conductivity	Purity, conductivity and easy forming have priority over high strength
1050	Minimum 99.5% aluminum with properties very close to 1060	The specification calls for 1050 or 1050A and high formability is required
1100	Commercially pure aluminum widely used for general fabrication	A broadly specified general-purpose pure aluminum grade is required
3003	Aluminum-manganese alloy with higher strength and good formability	The finished part needs more mechanical strength while retaining good forming performance



These grades should not be considered automatically interchangeable. The required chemical composition, mechanical properties, temper and designation system must follow the standard stated on the drawing, purchase order or material specification.



What Affects 1060 Aluminum Sheet and Coil Price?



There is no single fixed 1060 aluminum sheet price or 1060 aluminum coil price for every order. The final quotation depends on aluminum raw-material cost, temper, thickness, width, coil or sheet format, order quantity, slitting or cut-to-length processing, surface protection, packing requirements and delivery destination.



For price comparison, make sure quotations use the same alloy standard, temper, dimensions, tolerance, coil weight, processing and packing conditions. A lower price based on a different specification may not represent the same finished material.



Quality Control and Export Supply



Depending on the purchase specification, inspection can cover chemical composition, temper, thickness, width, sheet length, flatness, surface condition, edge quality, coil inner diameter, coil weight and packing. Mill test certificates or third-party inspection requirements should be confirmed before production.



1060 aluminum sheet and coil can be packed with moisture-resistant wrapping, paper or film protection, edge guards, steel strapping, wooden pallets or wooden cases according to the product form and transport requirement. The objective is to reduce moisture exposure, movement, edge damage and surface scratching during international shipment.



For an accurate quotation, provide the required alloy and standard, temper, thickness, width, sheet length or coil specification, quantity, application, surface requirement, protective film, tolerance, test-document requirement and destination port.



When 1060 Aluminum Is Not the Best Choice



1060 should not be chosen simply because it is highly formable or commercially pure. For load-bearing structures, severe marine service, pressure components, demanding machining or parts that require substantially higher strength, alloys such as 3003, 5052, 5083 or 6061 may be more suitable. Final material selection should be based on the drawing, forming process, required mechanical properties and service environment.



Frequently Asked Questions



Is 1060 aluminum pure aluminum? 1060 is commercially pure aluminum rather than laboratory-pure aluminum. The grade contains at least 99.6% aluminum, with controlled limits for silicon, iron, copper and other elements.



Is 1060 aluminum heat treatable? No. 1060 is a non-heat-treatable aluminum grade. Its strength is increased mainly through cold working, which produces O, H12, H14, H18, H24 and other commonly specified tempers.



What is the difference between 1060-H14 and 1060-H24? Both are commonly used half-hard conditions, but they are produced through different strain-hardening and annealing routes. The final mechanical requirements should be checked against the applicable material standard and thickness.



Which 1060 temper is best for bending or deep drawing? O temper provides the highest formability. H12 or H14 can be considered when the component also needs moderate stiffness. The correct choice depends on thickness, bend radius, forming direction and part geometry.



Can 1060 mill finish aluminum be anodized or painted? Yes. 1060 aluminum can be anodized, polished, painted, printed or laminated after suitable cleaning and pretreatment. Decorative appearance should be confirmed by sample when surface consistency is important.



What is the difference between 1050 and 1060 aluminum? Both are commercially pure 1xxx-series grades. 1060 has a minimum aluminum content of 99.6%, while 1050 has a minimum aluminum content of 99.5%. In many applications their performance is similar, so the material designation required by the drawing or standard should determine the final choice.



What information is needed for a 1060 aluminum quotation? Please provide the alloy and standard, temper, thickness, width, sheet length or coil weight, quantity, surface requirement, application, tolerance, protective film, destination and required inspection documents.



Request a Quote for 1060 Aluminum Sheet or Coil



Henan Worthwill Industry Co., Ltd. supplies 1060 mill finish aluminum sheet, coil and slit material for electrical, forming, heat-transfer and general industrial applications. Send your specification, drawing or target application, and our team will review the suitable temper, dimensions, processing, packing and delivery requirements before quotation.
